Time-Current characteristic: Time-Lag(T)
Breaking Capacity: 2.5KA@75VDC, 5.0KA@60VDC
Standard: UL 248-1
Approvals: cURus
Material: Tube- ceramics, end caps- copper silver plated
Operation Temperature: -55℃ ~ +125℃
Weldability: 260℃≤5 seconds(wave-soldering), 350℃≤3 seconds(hand welding)
Soldering Peak: 260℃, 10 seconds, /280℃, 5 seconds
Storage conditions: +10℃ ~ +60℃,average annual relative humidity ≤75%,dry maximum value of 30 days is 95%
