Time-current characteristics: fast-acting (F)

Breaking capacity: 35A@32VDC

Standard: UL 248-14

Certification: cURus

Material: matrix-ceramic, both ends-silver nickel and tin plated

Working temperature: -55℃ ~ +150℃

Solderability: 260℃≤5 seconds (wave soldering); 350℃≤3 seconds (manual soldering)

Welding temperature bearing capacity: 260℃, 10 seconds; 280℃, 5 seconds

Storage conditions: +10℃ ~ +60℃; the annual average relative humidity is less than or equal to 75%, and the maximum relative humidity can not exceed 30 days when the relative humidity reaches 95%
